4525-DS5A001DP - TE Connectivity

4525-DS5A001DP Details

• Manufacturer Part Number:

  4525-DS5A001DP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE - 8

• Factory Lead Time:

  16 Weeks, 3 Days

• Manufacturer:

  TE Connectivity

• Accuracy-Max (%):

  0.25%

• Additional Feature:

  PORT HEIGHT = 7.5 MM, DIAMETER = 3.5 MM

• Body Breadth:

  9.9 mm

• Body Height:

  9.9 mm

• Body Length or Diameter:

  12.5 mm

• Housing:

  CERAMIC

• Mounting Feature:

  THROUGH HOLE MOUNT

• Operating Current-Max:

  3 mA

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -25 °C

• Output Range:

  0.5-4.5V

• Output Type:

  ANALOG VOLTAGE

• Package Shape/Style:

  RECTANGULAR

• Port Type:

  BARBED

• Pressure Range-Max:

  0.986 Psi

• Pressure Range-Min:

  -20 Psi

• Pressure Sensing Mode:

  DIFFERENTIAL

• Response Time:

  1000 µs

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER
