4525DO-TP5BI015AP - TE Connectivity

4525DO-TP5BI015AP Details

• Manufacturer Part Number:

  4525DO-TP5BI015AP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-8

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Accuracy-Max (%):

  0.25%

• Additional Feature:

  Port Diameter = 3.5 MM and Port Height = 7.8 MM

• Body Breadth:

  9.9 mm

• Body Height:

  4.1 mm

• Body Length or Diameter:

  12.4 mm

• Housing:

  CERAMIC

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Bits:

  14

• Operating Current-Max:

  3 mA

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -25 °C

• Output Interface Type:

  I2C INTERFACE

• Output Type:

  DIGITAL CURRENT

• Package Shape/Style:

  RECTANGULAR

• Port Type:

  BARBED

• Pressure Range-Max:

  15 Psi

• Pressure Sensing Mode:

  ABSOLUTE

• Sensors/Transducers Type:

  PRESSURE SENSOR,PIEZORESISTIVE

• Surface Mount:

  NO

• Termination Type:

  SOLDER
