47-100001 - CONEC

47-100001 Details

• Manufacturer Part Number:

  47-100001

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Conec Corporation

• YTEOL:

  0

• Body Depth:

  0.699 inch

• Body Length:

  2.406 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S72P24

• Contact Finish Mating:

  AU ON NI

• Contact Finish Termination:

  TIN

• Contact Gender:

  MALE

• Contact Material:

  COPPER ALLOY

• Contact Resistance:

  25 mΩ

• Durability:

  200 Cycles

• Filter Feature:

  NO

• Insulator Color:

  GRAY

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Reference Standard:

  UL

• Terminal Length:

  0.146 inch

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  96
