47136 - MYRRA

47136 Details

• Manufacturer Part Number:

  47136

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  PACKAGE-10/4

• ECCN Code:

  EAR99

• Manufacturer:

  Myrra

• Additional Feature:

  120 -370VDC INPUT ALSO AVAILABLE

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CUL, EN, IEC, UL, VDE

• Efficiency (Main Output):

  74%

• Input Voltage-Max:

  265 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-PDMA-P4

• Length:

  32.3 mm

• Line Regulation-Max:

  3%

• Load Regulation-Max:

  5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  0.13 A

• Output Voltage-Max:

  3.36 V

• Output Voltage-Min:

  3.04 V

• Output Voltage-Nom:

  3.2 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Seated Height-Max:

  22.3 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  5 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  3.2 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  3.05 s

• Width:

  27.3 mm
