47243 - MYRRA

47243 Details

• Manufacturer Part Number:

  47243

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  PACKAGE-10/5 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Myrra

• Additional Feature:

  IT ALSO HAS VOUT2=7V

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, CAN, CSA, VDE, IEC, CE

• Efficiency (Main Output):

  72%

• Input Voltage-Max:

  265 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-PDMA-P5

• Length:

  33.3 mm

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  50 °C

• Operating Temperature-Min:

  -25 °C

• Output Current-Max:

  0.38 A

• Output Voltage-Max:

  10.71 V

• Output Voltage-Min:

  10.29 V

• Output Voltage-Nom:

  10.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  THERMAL; OUTPUT OVER CURRENT; SHORT CIRCUIT

• Screening Level:

  IEC 62368-1

• Seated Height-Max:

  22.3 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  5 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  4.7 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  2 s

• Width:

  28.3 mm
