50-29-1412 - Molex

50-29-1412 Details

• Manufacturer Part Number:

  50-29-1412

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  6.75

• Additional Feature:

  POLARIZED, SHROUDED

• Board Mounting Option:

  PEG

• Body Breadth:

  0.74 inch

• Body Depth:

  0.42 inch

• Body Length:

  0.98 inch

• Body/Shell Style:

  SOCKET

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Arrangement:

  S0P12

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  MALE AND FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Empty Shell:

  YES

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  15.1232 N

• Insulator Color:

  BLACK

• Insulator Material:

  POLYESTER

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Rows Loaded:

  3

• Option:

  GENERAL PURPOSE

• Reference Standard:

  UL

• Terminal Pitch:

  5.0292 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  12

• UL Flammability Code:

  94V-0
