50DP45-01-1-AJN - Grayhill

50DP45-01-1-AJN Details

• Manufacturer Part Number:

  50DP45-01-1-AJN

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.20

• Manufacturer:

  Grayhill Inc

• YTEOL:

  7

• Actuator Type:

  ADJUSTABLE STOP TYPE

• Body Height:

  13.64 mm

• Body Length or Diameter:

  12.7 mm

• Contact (AC) Max Rating R Load:

  .15A@115VAC

• Contact Current(AC)-Max:

  0.15 A

• Contact Current(DC)-Max:

  0.2 A

• Contact (DC) Max Rating R Load:

  .2A@28VDC

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Electrical Life:

  25000 Cycle(s)

• Indexing Angle:

  45 deg

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  8

• Number of Switch Sections:

  1

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP8T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Termination Type:

  SOLDER
