516-090-000-402 - EDAC

516-090-000-402 Details

• Manufacturer Part Number:

  516-090-000-402

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  EDAC Inc

• YTEOL:

  7.2

• Additional Feature:

  POLARIZED

• Board Mounting Option:

  #2-56 UNC INSERT

• Body Breadth:

  1.234 inch

• Body Depth:

  0.798 inch

• Body Length:

  2.718 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  RACK AND PANEL CONNECTOR

• Contact Finish Mating:

  GOLD OVER NICKEL

• Contact Finish Termination:

  Gold (Au) - with Nickel (Ni) barrier

• Contact Gender:

  HERMAPHRODITIC

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  10 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  2000VAC V

• Empty Shell:

  YES

• Filter Feature:

  NO

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  GRAY

• Insulator Material:

  POLYCARBONATE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mating Contact Pitch:

  0.15 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Option 2:

  JACKSCREW

• Mounting Style:

  STRAIGHT

• Mounting Type:

  CABLE AND PANEL

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• Polarization Key:

  POLAR PIN POSITION

• Rated Current (Signal):

  8.5 A

• Reference Standard:

  UL

• Terminal Length:

  0.9 inch

• Termination Type:

  CRIMP

• Total Number of Contacts:

  90

• UL Flammability Code:

  94V-0
