5212044-1 - TE Connectivity

5212044-1 Details

• Manufacturer Part Number:

  5212044-1

• Brand Name:

  AMP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Factory Lead Time:

  10 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Board Mounting Option:

  SOLDERABLE RETENTION CLIPS

• Body Breadth:

  0.82 inch

• Body Depth:

  0.606 inch

• Body Length:

  0.86 inch

• Body/Shell Style:

  RECEPTACLE

• Cable Types:

  DISCRETE

• Connector Type:

  DIN CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  STAGGERED

• Contact Pitch Circle Diameter:

  6.98 mm

• DIN Conformance:

  NO

• Durability:

  100 Cycles

• EMI Shielded:

  YES

• Empty Shell:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insertion Force-Max:

  13.344 N

• Insulation Resistance:

  5000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYAMIDE

• MIL Conformance:

  NO

• Mains Connector Rating:

  7.5A

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Plating Thickness:

  100u inch

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  7.5 A

• Reference Standard:

  UL

• Shell Finish:

  TIN-NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.14 inch

• Terminal Pitch:

  2.49 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  5

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  4.448 N
