531719-1 - TE Connectivity

531719-1 Details

• Manufacturer Part Number:

  531719-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Additional Feature:

  STANDARD: MIL-C-55302

• Board Mounting Option:

  HOLE .099-.111

• Body Breadth:

  0.33 inch

• Body Depth:

  0.77 inch

• Body Length:

  1.255 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Gender:

  MALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  SQ PIN-SKT

• DIN Conformance:

  NO

• Filter Feature:

  NO

• IEC Conformance:

  NO

• MIL Conformance:

  YES

• Mating Contact Pitch:

  0.075 inch

• Mating Contact Row Spacing:

  0.125 inch

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  3.81 mm

• Plating Thickness:

  50u inch

• Polarization Key:

  SHRD ENDS

• Terminal Length:

  0.125 inch

• Terminal Pitch:

  1.91 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  10
