536EL10001IT5 - CTS

536EL10001IT5 Details

• Manufacturer Part Number:

  536EL10001IT5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Factory Lead Time:

  24 Weeks

• Manufacturer:

  CTS Corporation

• YTEOL:

  8.65

• Additional Feature:

  ENABLE/DISABLE FUNCTION

• Aging:

  1 PPM/FIRST YEAR

• Fall Time-Max:

  8 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.1%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  10

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS

• Output Load:

  15 pF

• Package Equivalence Code:

  LCC10,.12X.2,50/40

• Physical Dimension:

  5.0mm x 3.2mm x 2.0mm

• Rise Time-Max:

  8 ns

• Supply Current-Max:

  10 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  GOLD OVER NICKEL
