5504-24-1 - Coto Technology

5504-24-1 Details

• Manufacturer Part Number:

  5504-24-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.60

• Manufacturer:

  Coto Technology USA

• YTEOL:

  8.7

• Additional Feature:

  SHIELDED

• Body Breadth:

  18.03 mm

• Body Height:

  19.05 mm

• Body Length or Diameter:

  71.12 mm

• Coil Current(DC)-Max:

  0.042 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  1008 mW

• Coil Release Voltage(DC):

  2 V

• Coil Resistance:

  575 Ω

• Coil Voltage(DC)-Max:

  30 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  3A@7500VAC

• Contact Current(AC)-Max:

  3 A

• Contact Current(DC)-Max:

  3 A

• Contact (DC) Max Rating R Load:

  3A@7500VDC

• Contact Resistance:

  200 mΩ

• Contact Voltage(AC)-Max:

  7500 V

• Contact Voltage(DC)-Max:

  7500 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  4

• Operate Time:

  3 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  71.12mm X 18.03mm X 19.05mm

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM B

• Relay Function:

  SPST

• Relay Type:

  DRY REED RELAY

• Release Time:

  3 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Tin (Sn)

• Terminal Length:

  0.005100330200660402 inch

• Termination Type:

  SOLDER
