553-0711-306F - Dialight

553-0711-306F Details

• Manufacturer Part Number:

  553-0711-306F

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Malaysia

• HTS Code:

  8541.40.20.00

• Manufacturer:

  Dialight

• YTEOL:

  6.25

• Additional Feature:

  HIGH RELIABILITY

• Color:

  RED/GREEN

• Color@Wavelength:

  Green/Red

• Configuration:

  12 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS

• Forward Current-Max:

  0.045 A

• Forward Voltage-Max:

  2 V

• JESD-609 Code:

  e4

• Luminous Intensity-Min:

  0.0063 cd

• Luminous Intensity-Nom:

  4.7/10.0 mcd

• Mounting Feature:

  RADIAL MOUNT

• Number of Functions:

  12

• Number of LEDs in Array:

  12

• Number of Terminals:

  24

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Optoelectronic Device Type:

  DUAL COLOR LED ARRAY

• Overall Height:

  9.65 mm

• Packing Method:

  BULK

• Peak Wavelength:

  635/565 nm

• Shape:

  ROUND

• Size:

  3 mm

• Surface Mount:

  NO

• T-code:

  T-1

• Terminal Finish:

  Copper/Nickel/Silver (Cu/Ni/Ag)

• Terminal Pitch:

  2.54 mm

• Viewing Angle:

  50 deg
