5646955-5 - TE Connectivity

5646955-5 Details

• Manufacturer Part Number:

  5646955-5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  20 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• Board Mounting Option:

  HOLE .078-.082

• Body Breadth:

  0.562 inch

• Body Depth:

  0.88 inch

• Body Length:

  0.709 inch

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S0P5

• Contact Finish Mating:

  AU-PD-NI ON NI

• Contact Finish Termination:

  TIN OVER NICKEL

• Contact Gender:

  MALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Resistance:

  5 mΩ

• Contact Style:

  BLADE PIN-SKT

• Dielectric Withstanding Voltage:

  1000VAC V

• Durability:

  250 Cycles

• Filter Feature:

  NO

• Insertion Force-Max:

  .973 N

• Insulation Resistance:

  10000000000 Ω

• Insulator Color:

  GRAY

• Insulator Material:

  POLYESTER

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Reference Standard:

  UL

• Terminal Length:

  0.127 inch

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  5

• Withdrawl Force-Min:

  .5004 N
