568-0701-111F - Dialight

568-0701-111F Details

• Manufacturer Part Number:

  568-0701-111F

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Malaysia

• HTS Code:

  8541.40.20.00

• Manufacturer:

  Dialight

• YTEOL:

  5

• Color:

  RED/GREEN

• Color@Wavelength:

  Green/Red

• Configuration:

  SEPARATE, 4 ELEMENTS

• Forward Current-Max:

  0.02 A

• Forward Voltage-Max:

  2.6 V

• JESD-609 Code:

  e4

• Lens Type:

  DIFFUSED

• Luminous Intensity-Nom:

  5.6/8.7 mcd

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Functions:

  4

• Number of LEDs in Array:

  2

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Optoelectronic Device Type:

  DUAL COLOR LED ARRAY

• Overall Height:

  20.32 mm

• Peak Wavelength:

  630/565 nm

• Reverse Voltage-Max:

  5 V

• Shape:

  CYLINDRICAL

• Size:

  3 mm

• Surface Mount:

  NO

• T-code:

  T-1

• Terminal Finish:

  Copper/Nickel/Silver (Cu/Ni/Ag)

• Terminal Pitch:

  1.91 mm

• Viewing Angle:

  200 deg
