57PC5M - Switchcraft

57PC5M Details

• Manufacturer Part Number:

  57PC5M

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Switchcraft Conxall

• YTEOL:

  7

• Additional Feature:

  POLARIZED

• Board Mounting Option:

  PEG

• Body Breadth:

  0.827 inch

• Body Depth:

  0.728 inch

• Body Length:

  0.835 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  DIN CONNECTOR

• Contact Gender:

  MALE

• Contact Pitch Circle Diameter:

  7 mm

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  YES

• EMI Shielded:

  NO

• IEC Conformance:

  NO

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED

• Termination Type:

  SOLDER

• Total Number of Contacts:

  5
