594750-E - TE Connectivity

594750-E Details

• Manufacturer Part Number:

  594750-E

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  3 Weeks, 4 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Additional Feature:

  STANDARDS: DIN 41612; IEC 60603-2

• Board Mounting Option:

  HOLE 0.11

• Body Breadth:

  0.583 inch

• Body Depth:

  0.398 inch

• Body Length:

  3.74 inch

• Connector Type:

  BOARD EURO CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT APPLICABLE

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  8 mΩ

• Contact Style:

  BLADE PIN-SKT

• Dielectric Withstanding Voltage:

  4300VAC V

• Durability:

  500 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000000 Ω

• Insulator Material:

  GLASS FILLED POLYBUTYLENE TEREPHTHALATE

• Mating Contact Pitch:

  0.4 inch

• Mating Contact Row Spacing:

  0.256 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Name of Rows Loaded:

  Z,D

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  10.16 mm

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Power):

  15 A

• Reference Standard:

  CSA,CUL,UL

• Terminal Length:

  0.169 inch

• Terminal Pitch:

  10.16 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  15

• UL Flammability Code:

  94V-0
