5962R0052001VVC - Renesas Electronics

5962R0052001VVC Details

• Manufacturer Part Number:

  5962R0052001VVC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-18

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  5.93

• Built-in Protections:

  TRANSIENT

• Interface IC Type:

  BUFFER OR INVERTER BASED PERIPHERAL DRIVER

• JESD-30 Code:

  R-CDIP-T18

• JESD-609 Code:

  e4

• Number of Functions:

  8

• Number of Terminals:

  18

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Qualified

• Screening Level:

  MIL-PRF-38535 Class V

• Seated Height-Max:

  5.08 mm

• Supply Voltage-Max:

  80 V

• Supply Voltage-Min:

  5 V

• Surface Mount:

  NO

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Dose:

  100k Rad(Si) V

• Turn-off Time:

  11 µs

• Turn-on Time:

  2 µs

• Width:

  7.62 mm
