5P49V5935B536LTGI - Renesas Electronics

5P49V5935B536LTGI Details

• Manufacturer Part Number:

  5P49V5935B536LTGI

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  LGA-24

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  3

• Additional Feature:

  IT ALSO OPERATES AT 2.5V AND 3.3V NOMINAL SUPPLY

• JESD-30 Code:

  S-XBGA-N24

• Length:

  4 mm

• Number of Terminals:

  24

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Clock Frequency-Max:

  350 MHz

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HLFLGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, HEAT SINK/SLUG, LOW PROFILE, FINE PITCH

• Primary Clock/Crystal Frequency-Nom:

  350 MHz

• Seated Height-Max:

  1.49 mm

• Supply Current-Max:

  34 mA

• Supply Voltage-Max:

  1.89 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  4 mm

• uPs/uCs/Peripheral ICs Type:

  CLOCK GENERATOR, PROGRAMMABLE
