6-1825011-1 - TE Connectivity

6-1825011-1 Details

• Manufacturer Part Number:

  6-1825011-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Factory Lead Time:

  19 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  7.95

• Actuator Color:

  NATURAL

• Actuator Length:

  0.025 inch

• Actuator Material:

  NYLON

• Actuator Travel:

  2.794 mm

• Actuator Type:

  FLUSH TOP TYPE

• Body Breadth:

  7.35 mm

• Body Height:

  4.45 mm

• Body Length or Diameter:

  25.4 mm

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  .3A@115VAC

• Contact Current(AC)-Max:

  0.3 A

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  .3A@115VDC

• Contact Function:

  ON-ON

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Electrical Life:

  15000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• Mounting Feature:

  PANEL MOUNT

• Number of Independent Keys:

  1

• Number of Positions:

  2

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TUBE

• Sealing:

  TAPE SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  6PDT

• Switch Type:

  SLIDE SWITCH

• Termination Type:

  SOLDER
