61312R - TE Connectivity

61312R Details

• Manufacturer Part Number:

  61312R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  19.69 mm

• Body Height:

  30.48 mm

• Body Length or Diameter:

  31.75 mm

• Coil Current(DC)-Max:

  0.02 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  240 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  600 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  15A@150VAC

• Contact Current(AC)-Max:

  15 A

• Contact Current(DC)-Max:

  15 A

• Contact (DC) Max Rating R Load:

  15A@28VDC

• Contact Voltage(AC)-Max:

  150 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  31.75mm x 19.69mm x 30.48mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
