6469152-1 - TE Connectivity

Description: Hard Metric Connectors HMZD 3PAIR HDR ASSY 37.5MM MOD

Download 6469152-1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
6469152-1 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
6469152-1 - TE Connectivity PCB footprint - Other - Other - 6469152-1-2
click to zoom
3D Models
6469152-1 - TE Connectivity - 3D model - Other - 6469152-1-2
click to zoom

6469152-1 Details

  • Manufacturer Part Number:

    6469152-1

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.69.40.40

  • Factory Lead Time:

    5 Weeks

  • Manufacturer:

    TE Connectivity

  • YTEOL:

    7.9

  • Body Breadth:

    0.745 inch

  • Body Depth:

    0.528 inch

  • Body Length:

    1.474 inch

  • Connector Type:

    BOARD CONNECTOR

  • Contact Finish Mating:

    NOT SPECIFIED

  • Contact Finish Termination:

    Matte Tin (Sn)

  • Contact Gender:

    MALE

  • Contact Material:

    NOT SPECIFIED

  • Contact Pattern:

    RECTANGULAR

  • Contact Style:

    SQ PIN-SKT

  • DIN Conformance:

    NO

  • Filter Feature:

    NO

  • IEC Conformance:

    NO

  • Insulator Material:

    GLASS FILLED POLYESTER

  • JESD-609 Code:

    e3

  • MIL Conformance:

    NO

  • Mating Contact Pitch:

    0.098 inch

  • Mating Contact Row Spacing:

    0.059 inch

  • Mixed Contacts:

    NO

  • Mounting Option 1:

    LOCKING

  • Mounting Style:

    STRAIGHT

  • Mounting Type:

    BOARD

  • Number Of Connectors:

    ONE

  • Number Of PCB Rows:

    9

  • Number of Rows Loaded:

    9

  • Option:

    GENERAL PURPOSE

  • PCB Contact Pattern:

    RECTANGULAR

  • PCB Contact Row Spacing:

    1.5 mm

  • Polarization Key:

    2WALL SHROUD

  • Reference Standard:

    UL

  • Terminal Length:

    0.098 inch

  • Terminal Pitch:

    2.5 mm

  • Termination Type:

    PRESS FIT

  • Total Number of Contacts:

    135

  • UL Flammability Code:

    94V-0
