66.22.9.024.0600S - FINDER

66.22.9.024.0600S Details

• Manufacturer Part Number:

  66.22.9.024.0600S

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  FINDER SpA

• YTEOL:

  7.67

• Body Breadth:

  33.5 mm

• Body Height:

  31 mm

• Body Length or Diameter:

  51.5 mm

• Coil Current(DC)-Max:

  0.071 A

• Coil Operate Voltage(DC):

  19.2 V

• Coil Power:

  1700 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  340 Ω

• Coil Voltage(DC)-Max:

  26.4 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  7500VA@440VAC

• Contact (AC) Max Rating R Load:

  50A@440VAC

• Contact Current(AC)-Max:

  50 A

• Contact Voltage(AC)-Max:

  440 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  Silver Cadmium Oxide

• Input Switching Control Type:

  Random

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  16

• Operate Time:

  8 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  51.5mm x 33.5mm x 31mm

• Reference Standard:

  CE; CSA; CUL; EAC; EX; IMQ; RINA; UKCA; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Sealing:

  RT2

• Surface Mount:

  NO

• Terminal Length:

  0.003987807975615951 inch

• Termination Type:

  SOLDER
