67.22.9.012.4300 - FINDER

67.22.9.012.4300 Details

• Manufacturer Part Number:

  67.22.9.012.4300

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  FINDER SpA

• Body Breadth:

  33 mm

• Body Height:

  57.5 mm

• Body Length or Diameter:

  51.5 mm

• Coil Operate Voltage(DC):

  10.8 V

• Coil Power:

  1700 mW

• Coil Resistance:

  85 Ω

• Coil Voltage(DC)-Max:

  13.2 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  20000VA@690VAC

• Contact (AC) Max Rating R Load:

  150A@690VAC

• Contact Current(AC)-Max:

  150 A

• Contact Voltage(AC)-Max:

  690 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  30000 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• Input Switching Control Type:

  Random

• Operate Time:

  35 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  51.5mm x 33mm x 57.5mm

• Reference Standard:

  IMQ; UL

• Relay Action:

  LATCHED

• Relay Form:

  2 FORM A

• Relay Function:

  DPST

• Release Time:

  4 ms

• Terminal Length:

  0.004500889001778004 inch

• Termination Type:

  SOLDER
