6TPC100M - Panasonic

6TPC100M Details

• Manufacturer Part Number:

  6TPC100M

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Indonesia, Japan

• ECCN Code:

  EAR99

• HTS Code:

  8532.21.00.50

• Factory Lead Time:

  111 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  0

• Additional Feature:

  ESR IS MEASURED AT 100 KHZ, RIPPLE CURRENT IS MEASURED AT 100KHZ, 45CEL

• Capacitance:

  100 µF

• Capacitor Type:

  TANTALUM CAPACITOR

• Dielectric Material:

  TANTALUM (SOLID POLYMER)

• ESR:

  45 mΩ

• Height:

  1.9 mm

• Leakage Current:

  0.063 mA

• Length:

  7.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, Embossed, 13 Inch

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  6.3 V

• Ripple Current:

  1700 mA

• Size Code:

  2917

• Surface Mount:

  YES

• Tan Delta:

  0.10

• Terminal Finish:

  Copper/Nickel/Palladium/Gold (Cu/Ni/Pd/Au)

• Terminal Shape:

  J BEND

• Width:

  4.3 mm
