7142-05-1010 - Coto Technology

7142-05-1010 Details

• Manufacturer Part Number:

  7142-05-1010

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mexico

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.60

• Manufacturer:

  Coto Technology USA

• YTEOL:

  6.9

• Additional Feature:

  SHIELDED

• Body Breadth:

  16.76 mm

• Body Height:

  9.52 mm

• Body Length or Diameter:

  30.23 mm

• Coil Current(DC)-Max:

  0.077 A

• Coil Operate Voltage(DC):

  3.75 V

• Coil Power:

  385 mW

• Coil Release Voltage(DC):

  0.4 V

• Coil Resistance:

  65 Ω

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.25A@150VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Rating R Load:

  0.25A@150VDC

• Contact Resistance:

  150 mΩ

• Contact Voltage(AC)-Max:

  150 V

• Contact Voltage(DC)-Max:

  150 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  10

• Operate Time:

  2 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  30.23mm x 16.76mm x 9.52mm

• Relay Action:

  BBM

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  DRY REED RELAY

• Release Time:

  2.5 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Length:

  0.003200406400812802 inch

• Termination Type:

  SOLDER
