71AF36-02-1-04S - Grayhill

71AF36-02-1-04S Details

• Manufacturer Part Number:

  71AF36-02-1-04S

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Grayhill Inc

• YTEOL:

  6

• Actuator Type:

  SHAFT TYPE

• Body Height:

  17.45 mm

• Body Length or Diameter:

  24.87 mm

• Contact (AC) Max Rating R Load:

  .3A@115VAC

• Contact Current(AC)-Max:

  0.3 A

• Contact Voltage(AC)-Max:

  115 V

• Electrical Life:

  15000 Cycle(s)

• Indexing Angle:

  36 deg

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  4

• Number of Switch Sections:

  1

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP4T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  GOLD OVER NICKEL

• Termination Type:

  SOLDER
