71BT36-02-1-06N - Grayhill

71BT36-02-1-06N Details

• Manufacturer Part Number:

  71BT36-02-1-06N

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Grayhill Inc

• YTEOL:

  7

• Actuator Length:

  0.375 inch

• Actuator Material:

  STEEL PASSIVATED

• Actuator Type:

  SHAFT TYPE

• Body Height:

  17.45 mm

• Body Length or Diameter:

  26.42 mm

• Bushing Diameter:

  0.375 inch

• Bushing Length:

  0.275 inch

• Bushing Type:

  3/8-32

• Center Contact Material:

  BERYLLIUM COPPER

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  .3A@115VAC

• Contact Current(AC)-Max:

  0.3 A

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(AC)-Max:

  115 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  15000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  GOLD

• Indexing Angle:

  36 deg

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  DIALLYL PHTHALATE

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  6

• Number of Switch Sections:

  1

• PCB Hole Count:

  36

• Sealing:

  FLUX FREE SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SP6T

• Switch Type:

  ROTARY SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Length:

  0.125 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
