74HCS595BQX footprint, schematic symbol and 3D model by Nexperia

Symbol

click to zoom

PCB Footprints

74HCS595BQX - Nexperia PCB footprint - Other - Other - SOT763-1_2026-1.1

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for 74HCS595BQX
Part Number 74HCS595BQX
Manufacturer Nexperia
Pin Count 17
Part Category Integrated Circuit
Package Category Other
Footprint Name Other - SOT763-1_2026-1.1
Released Date Jun 3, 2026
Last Modified Date Jun 3, 2026 1:10 PM UTC
Pinout / Pin List Click Here (Member Only)

74HCS595BQX Details

Manufacturer Part Number:
74HCS595BQX
Part Life Cycle Code:
Active
HTS Code:
8542.39.00.60
Manufacturer:
Nexperia
Logic IC Type:
SERIAL IN PARALLEL OUT

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

74HCS595BQX Overview

Use the download button to access the 74HCS595BQX schematic symbol and PCB footprint.

To find more CAD model downloads similar to this part, try a partial part number search, like 74HCS, or try a keyword search, such as Shift Registers
