The maximum clock frequency of the 74HCT165D is 30 MHz, but it can vary depending on the operating voltage and load conditions. It's recommended to check the timing characteristics in the datasheet and perform simulations or testing to ensure reliable operation.
To ensure proper power supply and decoupling, connect the VCC pin to a stable 5V power supply, and decouple the power supply lines with 100nF capacitors as close to the device as possible. Additionally, use a 10uF capacitor to decouple the power supply lines from the rest of the circuit.
The maximum input voltage of the 74HCT165D is 5.5V, which is the absolute maximum rating. However, it's recommended to keep the input voltage within the recommended operating range of 4.5V to 5.5V to ensure reliable operation.
The asynchronous reset input (RST) of the 74HCT165D should be connected to a pull-up resistor to ensure that it is not left floating. When the RST input is low, the device is reset, and all outputs are set to low. When the RST input is high, the device operates normally.
The propagation delay of the 74HCT165D varies depending on the operating voltage and temperature. The typical propagation delay is around 10ns to 20ns, but it can be as high as 30ns under certain conditions. Check the datasheet for more information on the propagation delay characteristics.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
74HCT165D Overview
Use the download button to access the 74HCT165D schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 74HCT,
or try a keyword search, such as Shift Registers
About Nexperia
Nexperia is a leading global player in the semiconductor industry. Specializing in essential electronic components, Nexperia offers a diverse range of products including discrete components, MOSFETs, logic ICs, and analog ICs. These components are integral to a multitude of applications across automotive, industrial, consumer electronics, and computing sectors, where reliability, performance, and efficiency are paramount.
