75581-0009 - Molex

75581-0009 Details

• Manufacturer Part Number:

  75581-0009

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• YTEOL:

  0

• Board Mounting Option:

  PEG

• Body Breadth:

  0.468 inch

• Body Depth:

  2.096 inch

• Body Length:

  1.585 inch

• Connector Type:

  PCI EXPRESS CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Pattern:

  STAGGERED

• Contact Style:

  PCIE CONNECTOR

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Material:

  POLYETHYLENE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2+2+2+2

• Number of Ports:

  1

• Number of Rows Loaded:

  2+2

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.5/2.5 mm

• Plating Thickness:

  15u inch

• Polarization Key:

  POLARIZED HOUSING

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.082 inch

• Terminal Pitch:

  1.6 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  136
