760475002 - Molex

760475002 Details

• Manufacturer Part Number:

  760475002

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China, USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Molex

• Additional Feature:

  10 PORTS, 20-POSITIONS EACH

• Board Mounting Option:

  PEG

• Body Breadth:

  1.016 inch

• Body Depth:

  2.49 inch

• Body Length:

  2.839 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  SFP CONNECTOR

• Contact Finish Mating:

  NOT APPLICABLE

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  COPPER ALLOY

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  10 mΩ

• Contact Style:

  SFP+ TYPE

• Dielectric Withstanding Voltage:

  300VAC V

• Durability:

  100 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e3

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number Of PCB Rows:

  4+4

• Number of Ports:

  10

• Number of Rows Loaded:

  2+2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.55 mm

• Plating Thickness:

  30u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  CSA; UL

• Shell Finish:

  NICKEL

• Shell Material:

  SILVER

• Terminal Length:

  0.081 inch

• Terminal Pitch:

  1.6 mm

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  200

• UL Flammability Code:

  94V-0
