760801321 - Würth Elektronik

760801321 Details

• Manufacturer Part Number:

  760801321

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Wurth Elektronik

• YTEOL:

  15

• Construction:

  Toroidal

• DC Resistance:

  0.042 Ω

• Inductance-Nom (L):

  720 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Lead Length:

  5.5 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -40 °C

• Package Diameter:

  99 mm

• Package Length:

  62 mm

• Package Style:

  Toroidal

• Packing Method:

  Tray

• Rated Current-Max:

  17.2 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  FLAT

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
