78446-3822 - Molex

78446-3822 Details

• Manufacturer Part Number:

  78446-3822

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Indonesia, Singapore

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  21 Weeks

• Manufacturer:

  Molex

• YTEOL:

  8

• Board Mounting Option:

  PEG

• Body Breadth:

  0.818 inch

• Body Depth:

  1.388 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Arrangement:

  S0P4

• Contact Finish Mating:

  AU ON NI

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  MALE

• Contact Material:

  COPPER ALLOY

• Contact Resistance:

  1 mΩ

• Contact Style:

  BLADE PIN-SKT

• Durability:

  200 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  20000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  GLASS FILLED LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e3

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Plating Thickness:

  30u inch

• Reference Standard:

  UL

• Terminal Length:

  0.098 inch

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  4
