7B-13.560MEEQ-T Frequently Asked Questions (FAQs)

• What is the recommended termination resistance for the 7B-13.560MEEQ-T?
  According to TXC Corporation's application notes, a 1 kΩ to 10 kΩ termination resistance is recommended to ensure stable oscillation and minimize jitter.
• How do I ensure the oscillator's start-up time meets my system's requirements?
  To minimize start-up time, ensure the power supply voltage is stable and within the recommended range. Additionally, a decoupling capacitor (e.g., 10 nF to 100 nF) close to the oscillator's power pins can help reduce start-up time.
• What is the maximum allowable frequency deviation for the 7B-13.560MEEQ-T?
  According to the datasheet, the maximum allowable frequency deviation is ±50 ppm over the operating temperature range. However, it's essential to consult with TXC Corporation or a qualified engineer to determine the specific requirements for your application.
• Can I use the 7B-13.560MEEQ-T in a harsh environment with high temperatures?
  While the 7B-13.560MEEQ-T is rated for operation up to 85°C, it's crucial to consider the specific environmental conditions of your application. Consult with TXC Corporation or a qualified engineer to determine the oscillator's suitability for your specific use case.
• What is the recommended PCB layout and routing for the 7B-13.560MEEQ-T?
  To minimize noise and ensure reliable operation, follow good PCB design practices, such as keeping the oscillator's signal traces short and away from noise sources, using a solid ground plane, and avoiding vias near the oscillator's pins.
