7UL1T08FS - Toshiba

7UL1T08FS Details

• Manufacturer Part Number:

  7UL1T08FS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  FSV-5

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• Family:

  AUP/ULP/V

• JESD-30 Code:

  R-PDSO-F5

• Length:

  1 mm

• Load Capacitance (CL):

  15 pF

• Logic IC Type:

  AND GATE

• Max I(ol):

  0.008 A

• Number of Functions:

  1

• Number of Inputs:

  2

• Number of Terminals:

  5

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  XSSOF

• Package Equivalence Code:

  FL5/6,.03,14

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, ULTRA THIN PROFILE, SHRINK PITCH

• Power Supply Current-Max (ICC):

  0.08 mA

• Prop. Delay@Nom-Sup:

  5.9 ns

• Propagation Delay (tpd):

  7.6 ns

• Schmitt Trigger:

  NO

• Seated Height-Max:

  0.5 mm

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.3 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  FLAT

• Terminal Pitch:

  0.35 mm

• Terminal Position:

  DUAL

• Width:

  0.8 mm
