825-22-005-10-001101 - Mill-Max

825-22-005-10-001101 Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-1.5 in-lbs (0.056-0.169 Nm) to ensure secure connections without damaging the terminals.
• Can I use this connector in high-vibration applications?
  Yes, the 825-22-005-10-001101 connector is designed to withstand high-vibration environments. However, it's essential to follow proper mounting and screw torque procedures to ensure reliable connections.
• Is this connector suitable for use in harsh environments, such as high temperatures or humidity?
  The connector is rated for operating temperatures between -55°C to 125°C and can withstand humidity up to 95%. However, it's crucial to follow the manufacturer's guidelines and consider additional environmental factors, such as salt spray or chemical exposure, when selecting a connector for harsh environments.
• What is the maximum wire size that can be used with this connector?
  The 825-22-005-10-001101 connector is designed to accommodate wire sizes between 24 AWG and 16 AWG. Using larger wire sizes may compromise the connection reliability and should be avoided.
• Can I use this connector in applications that require high-current carrying capacity?
  The connector is rated for a maximum current of 5A per contact. If your application requires higher current carrying capacity, you may need to consider alternative connectors or consult with the manufacturer for custom solutions.
