892H-1CH-C12VDC - Song Chuan

892H-1CH-C12VDC Details

• Manufacturer Part Number:

  892H-1CH-C12VDC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• ECCN Code:

  EAR99

• Manufacturer:

  Song Chuan Precision Company

• YTEOL:

  0.4

• Additional Feature:

  RATINGS ARE AS PER NO AND NC RATING IS 5A/277VAC; 1200VA@277VAC

• Body Breadth:

  10.3 mm

• Body Height:

  16 mm

• Body Length or Diameter:

  20 mm

• Coil Current(DC)-Max:

  0.033 A

• Coil Operate Voltage(DC):

  9.6 V

• Coil Power:

  400 mW

• Coil Release Voltage(DC):

  0.6 V

• Coil Resistance:

  360 Ω

• Coil Voltage(DC)-Max:

  19.2 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  1680VA@277VAC

• Contact (AC) Max Rating R Load:

  10A@277VAC

• Contact Current(AC)-Max:

  10 A

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  277 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER TIN OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  5

• Operate Time:

  10 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  20mm x 10.3mm x 16mm

• Reference Standard:

  CSA; CUL; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  5 ms

• Surface Mount:

  NO

• Terminal Length:

  0.0037084074168148335 inch

• Termination Type:

  SOLDER
