Description:Provides high-performance I/O expansion and switching functions between a PCIe upstream port and two downstream ports or peer-to-peer switching between downstream ports.
Renesas provides a recommended PCB layout guide in their application note (APN) document, which includes thermal vias, copper pours, and component placement guidelines to ensure optimal thermal performance.
Renesas recommends using an external power sequencer or a dedicated power management IC to ensure proper power sequencing. The datasheet provides guidelines for power-up and power-down sequences, and Renesas also offers a power sequencing application note for reference.
Renesas recommends using high-quality, low-ESR decoupling capacitors with a value of 10uF to 22uF, placed as close as possible to the power pins. The datasheet provides a recommended decoupling capacitor layout and Renesas also offers a decoupling capacitor selection guide.
Renesas provides a troubleshooting guide in their application note, which covers common issues such as power-on reset, clocking, and interface problems. Additionally, Renesas offers a support portal with FAQs, knowledge base articles, and technical support resources.
The 89HPES3T3ZBBCGI is rated for operation in the industrial temperature range (-40°C to 85°C) and is designed to meet various environmental standards, including RoHS and REACH. Renesas provides detailed information on operating conditions, including voltage, current, and power consumption, in the datasheet.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
89HPES3T3ZBBCGI Overview
Use the download button to access the 89HPES3T3ZBBCGI schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like 89HPE,
or try a keyword search, such as Bus Controllers
![89HPES3T3ZBBCGI - Renesas Electronics - 3D model - BGA - 144-LEAD BGA [13 X 13]](https://media.componentsearchengine.com/images/available.svg?v=0.75.1)
