89HPES5T5ZBBC - Renesas Electronics

89HPES5T5ZBBC Details

• Manufacturer Part Number:

  89HPES5T5ZBBC

• Brand Name:

  Renesas

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  CABGA

• Package Description:

  CABGA-196

• Pin Count:

  196

• Manufacturer Package Code:

  BC196

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO REQUIRES 3.3V SUPPLY

• Bus Compatibility:

  SMBUS

• Clock Frequency-Max:

  125 MHz

• Data Transfer Rate-Max:

  2500 MBps

• JESD-30 Code:

  S-PBGA-B196

• Length:

  15 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  196

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA196,14X14,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  225

• Seated Height-Max:

  1.76 mm

• Supply Current-Max:

  385 mA

• Supply Voltage-Max:

  1.1 V

• Supply Voltage-Min:

  0.9 V

• Supply Voltage-Nom:

  1 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  15 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, PCI
