8F2012-Z - Nidec Copal

8F2012-Z Details

• Manufacturer Part Number:

  8F2012-Z

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Nidec Copal Electronics Corporation

• YTEOL:

  7

• Actuator Angle:

  24 deg

• Actuator Length:

  0.413 inch

• Actuator Type:

  TOGGLE

• Body Breadth:

  13.0048 mm

• Body Height:

  8.9916 mm

• Body Length or Diameter:

  13.0048 mm

• Bushing Diameter:

  0.25 inch

• Bushing Length:

  0.413 inch

• Bushing Type:

  1/4-40

• Contact (AC) Max Rating R Load:

  3A@250VAC

• Contact Current(AC)-Max:

  3 A

• Contact Current(DC)-Max:

  4 A

• Contact (DC) Max Rating R Load:

  4A@30VDC

• Contact Function:

  ON-ON

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  30 V

• Mounting Feature:

  PANEL MOUNT

• Surface Mount:

  NO

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Length:

  0.209 inch

• Termination Type:

  SOLDER
