8L02-05-01 - Coto Technology

8L02-05-01 Details

• Manufacturer Part Number:

  8L02-05-01

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.60

• Manufacturer:

  Coto Technology USA

• YTEOL:

  0

• Additional Feature:

  WITH DIODE

• Body Breadth:

  6.85 mm

• Body Height:

  6.6 mm

• Body Length or Diameter:

  19.68 mm

• Coil Current(DC)-Max:

  0.025 A

• Coil Operate Voltage(DC):

  3.8 V

• Coil Power:

  125 mW

• Coil Release Voltage(DC):

  0.5 V

• Coil Resistance:

  200 Ω

• Coil Voltage(DC)-Max:

  6.5 V

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.5A@200VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Power Rating R Load:

  10W@200VDC

• Contact (DC) Max Rating R Load:

  0.5A@200VDC

• Contact Resistance:

  150 mΩ

• Contact Voltage(AC)-Max:

  200 V

• Contact Voltage(DC)-Max:

  200 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  500000000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• JESD-609 Code:

  e3

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  8

• Operate Time:

  0.5 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Physical Dimension:

  19.68mm x 6.85mm x 6.6mm

• Reference Standard:

  UL

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM A

• Relay Function:

  DPST

• Relay Type:

  DRY REED RELAY

• Release Time:

  0.5 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Length:

  0.003599187198374397 inch

• Termination Type:

  SOLDER
