8N0QV01EH-0110CDI - Renesas Electronics

8N0QV01EH-0110CDI Details

• Manufacturer Part Number:

  8N0QV01EH-0110CDI

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  CLCC

• Pin Count:

  10

• Manufacturer Package Code:

  CD10

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  ENABLE/DISABLE FUNCTION

• Control Voltage-Max:

  3.3 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  727.5 ppm

• Frequency Stability:

  100%

• JESD-609 Code:

  e4

• Linearity:

  5%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  10

• Operating Frequency-Max:

  260 MHz

• Operating Frequency-Min:

  15.476 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVCMOS/LVTTL

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  LCC10,.2X.28,100

• Physical Dimension:

  7.0mm x 5.0mm x 1.55mm

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  GOLD
