90HBJ04PRT - Grayhill

90HBJ04PRT Details

• Manufacturer Part Number:

  90HBJ04PRT

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Grayhill Inc

• YTEOL:

  6.7

• Actuator Material:

  POLYETHYLENE

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  APPROVAL: UL

• Body Breadth:

  7.37 mm

• Body Height:

  4.19 mm

• Body Length or Diameter:

  11.9 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@6VDC

• Contact Function:

  OFF-ON

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(DC)-Max:

  6 V

• Dielectric Withstand Volts:

  500VRMS V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD

• Housing Material:

  POLYETHYLENE

• Insulation Resistance:

  5000000000 Ω

• Insulator Material:

  POLYETHYLENE

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  4

• Number of Switch Sections:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Sealing:

  MOISTURE PROOF; TOP TAPE SEALED

• Solderability:

  REFLOW

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  MATTE TIN

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
