929 - Keystone Electronics

929 Details

• Manufacturer Part Number:

  929

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Keystone Electronics Corp

• Board Mounting Option:

  PEG

• Body Breadth:

  0.327 inch

• Body Depth:

  0.654 inch

• Body Length:

  0.531 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  IEEE 1394 CONNECTOR

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  FEMALE

• Contact Material:

  PHOSPHOR BRONZE

• Contact Resistance:

  15 mΩ

• Dielectric Withstanding Voltage:

  750VAC V

• Durability:

  1500 Cycles

• Insertion Force-Max:

  5.7824 N

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYETHYLENE

• Mounting Option 1:

  DETENT

• Mounting Option 2:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Ports:

  1

• Operating Temperature-Max:

  40 °C

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  2.007 mm

• Plating Thickness:

  FLASH inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Shell Material:

  PHOSPHOR BRONZE

• Terminal Pitch:

  2.006 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  6

• Withdrawl Force-Min:

  1.668 N
