9993960000 - Weidmüller

Description: PCB terminal, 320 V, 17.5 A, Pitch in mm: 5.08, 2.5 mm², Number of poles: 8, Clamping yoke connection, THT solder connection, 90°, Box

Download 9993960000 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
9993960000 - Weidmüller - PCB symbol
click to zoom
PCB Footprints
9993960000 - Weidmüller PCB footprint - Header, Shrouded - Straight PTH Box - Header, Shrouded - Straight PTH Box - 9993960000
click to zoom
3D Models
9993960000 - Weidmüller - 3D model - Header, Shrouded - Straight PTH Box - 9993960000
click to zoom

9993960000 Details

  • Manufacturer Part Number:

    9993960000

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Factory Lead Time:

    12 Weeks, 1 Day

  • Manufacturer:

    Weidmüller Interface GmbH & Co. KG

  • YTEOL:

    6

  • Additional Feature:

    STANDARD: UL 94V-0

  • Fastening Method:

    SCREW

  • Mounting Type:

    BOARD

  • Number of Decks:

    1

  • Number of Rows:

    1

  • Number of Ways:

    8

  • Rated Current:

    17.5 A

  • Rated Voltage:

    630 V

  • Safety Approval:

    CSA; UL

  • Terminal and Terminal Block Type:

    BARRIER STRIP TERMINAL BLOCK

  • Wire Cross Section:

    2.5 mm2

  • Wire Gauge:

    14 AWG

9993960000 Frequently Asked Questions (FAQs)

  • The operating temperature range of the 9993960000 is -40°C to 70°C.
  • Yes, the 9993960000 is compatible with industrial protocols such as Modbus and Profibus, making it suitable for industrial automation applications.
  • The maximum data transfer rate of the 9993960000 is 100 Mbps.
  • Yes, the 9993960000 has built-in surge protection, which helps to protect the device from voltage spikes and surges.
  • Yes, the 9993960000 is designed for use in hazardous locations and meets the requirements for explosion protection.
