A101MD9AB04 - TE Connectivity

A101MD9AB04 Details

• Manufacturer Part Number:

  A101MD9AB04

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  25 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Actuator Finish:

  NICKEL

• Actuator Length:

  0.27 inch

• Actuator Type:

  SHORT TYPE

• Body Breadth:

  12.7 mm

• Body Height:

  6.86 mm

• Body Length or Diameter:

  12.7 mm

• Bushing Length:

  0.28 inch

• Center Contact Plating:

  GOLD

• Contact Current(AC)-Max:

  0.4 A

• Contact Current(DC)-Max:

  0.4 A

• Contact Function:

  ON-ON

• Contact Resistance:

  0.01 mΩ

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Dielectric Withstand Volts:

  1000 V

• End Contact Material:

  COPPER ALLOY

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPDT

• Switch Type:

  TOGGLE SWITCH

• Termination Type:

  SOLDER
