A101SD9AV2Q04 - TE Connectivity

A101SD9AV2Q04 Details

• Manufacturer Part Number:

  A101SD9AV2Q04

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Actuator Finish:

  NICKEL

• Bushing Length:

  0.28 inch

• Center Contact Plating:

  SILVER

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact Function:

  ON-ON

• Contact Resistance:

  0.01 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  28 V

• Dielectric Withstand Volts:

  1000 V

• End Contact Material:

  COPPER ALLOY

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Function:

  SPDT

• Switch Type:

  TOGGLE SWITCH

• Termination Type:

  SOLDER
