A1252WV-S-F-2X5P - CJT

A1252WV-S-F-2X5P Details

• Manufacturer Part Number:

  A1252WV-S-F-2x5P

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  CJT Changjiang Connectors Co Ltd

• Board Mounting Option:

  PEG

• Body Breadth:

  0.285 inch

• Body Depth:

  0.189 inch

• Body Length:

  0.492 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  BOARD CONNECTOR

• Contact Finish Mating:

  AU

• Contact Finish Termination:

  GOLD

• Contact Gender:

  MALE

• Contact Material:

  BRASS

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  30 mΩ

• Contact Style:

  SQ PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Filter Feature:

  NO

• Insulation Resistance:

  500000000 Ω

• Mating Contact Pitch:

  0.049 inch

• Mating Contact Row Spacing:

  0.049 inch

• Mixed Contacts:

  NO

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  2

• Number of Rows Loaded:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Contact Pattern:

  RECTANGULAR

• PCB Contact Row Spacing:

  5.9944 mm

• Plating Thickness:

  FLASH inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Terminal Pitch:

  1.2446 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  10
