A1454KLETR-4N-T - Allegro Microsystems

Description: 3 V Hall-Effect Linear Sensor with I?C Output

Download A1454KLETR-4N-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
A1454KLETR-4N-T - Allegro Microsystems PCB footprint - Other - Other - Package LE, 8-Pin eTSSOP
click to zoom
3D Models
A1454KLETR-4N-T - Allegro Microsystems  - 3D model - Other - Package LE, 8-Pin eTSSOP
click to zoom

A1454KLETR-4N-T Details

  • Manufacturer Part Number:

    A1454KLETR-4N-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Manufacturer:

    Allegro MicroSystems LLC

  • YTEOL:

    7

  • Body Breadth:

    3 mm

  • Body Height:

    0.95 mm

  • Body Length or Diameter:

    4.4 mm

  • Housing:

    PLASTIC

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    8

  • Operating Current-Max:

    5 mA

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    OPEN-DRAIN

  • Output Interface Type:

    I2C INTERFACE

  • Output Range:

    0.36V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Equivalence Code:

    TSSOP8,.25

  • Package Shape/Style:

    RECTANGULAR

  • Sensors/Transducers Type:

    MAGNETIC FIELD SENSOR,HALL EFFECT

  • Supply Voltage-Max:

    3.5 V

  • Supply Voltage-Min:

    2.65 V

  • Surface Mount:

    YES

  • Technology:

    BICMOS

  • Termination Type:

    SOLDER
